TUBE FILLING SYSTEMS



SINGLE HEAD TUBE FILLING MACHINE-60/MIN
Machine Dimension - 2300 mm(L) * 1110 mm(W) * 2400 mm(H)
Design Speed -  60 cycle /min
Filling Range - 1.5 to 250cc
Filling Accuracy - +/-1%
Tube Diameter - Ø16 to 40mm max (Laminated tube)
Ø10 to 40mm max (Aluminium Tube)
Tube Length - 80 to 205mm max
Viscosity Range - 1000 - 300000 CPS
Option to seal - PBL/ABL/Aluminium/Extrusion/Co-Extrusion
Utility Details - Power - 4.25 kW
Compressed Air Pressure - 6 Bar Max.
Chilled water - 8 – 10°C

The above specification is subject to change without prior notice

Please contact us for more details
